The NY8A053E is an 8-bit microcontroller with EPROM as memory, designed for multi-IO applications such as remote controls, fan/light controls, or video instrument peripherals. CMOS process and at the same time to provide customers with low cost, high performance and other significant advantages. The NY8A053E core is built on the RISC Reduced instruction set architecture for easy editing and control, with a total of 55 instructions. Except for a few instructions that require 2 sequences, most instructions can be completed in 1 sequence, allowing users to easily complete different applications with program control. Therefore, it is ideal for a variety of low and medium memory capacity but complex applications.
    In terms of I/O resources, the NY8A053E has 12 elastic bidirectional I/O pins, each with a separate register control as an input or output pin. And each I/O pin has additional program-controlled functions such as pull or pull down resistance or Open-Drain output. In addition, for infrared remote control products, NY8A053E has built-in infrared carrier transmitter with selectable frequency.
    The NY8A053E has two sets of timers that can be counted at the system frequency for general timing applications or triggered from an external signal. In addition, the NY8A053E offers four sets of 10-bit resolution PWM outputs or buzzer outputs that can be used to drive motors, leds, or buzzers.
    NY8A053E uses a dual clock mechanism, high speed oscillation or low speed oscillation can be selected respectively internal RC oscillation or external Crystal input. In the dual-clock mode, the NY8A053E can select multiple working modes, such as Normal mode, Slow mode, Standby mode, and sleep mode, to save power consumption and extend battery life. And when the microcontroller uses the internal RC high-speed oscillation, the low-speed oscillation can be simultaneously timed using the external precise Crystal. It can maintain high-speed processing while accurately calculating the true time.
    In the power saving mode, such as Standby mode and sleep mode, various events can trigger the NY8A053E to wake up in Normal or Slow mode to deal with emergencies.

Wide operating voltage:
2.0V ~ 5.5V @ System frequency ≦8MHz.
2.2V ~ 5.5V @ System frequency > 8MHz.
Wide operating temperature: -40°C~85°C.
1Kx14 bits EPROM.
64 bytes SRAM.
Built-in accurate low voltage detection circuit (LVD). 14 Level 2.2v to 4.15v
An accurate Voltage Comparator is built in.
12 I/O pins (GPIO), PA[3:0], PB[7:0] that can separately control the input and output directions.
PA[3:0] and PB[3:0] can be optionally input with built-in pull-down resistors.
PB[7:0] has the option of pull-up resistance or Open-Drain output.
PB[3] can be selected as input or Open-Drain.
8-layer Stack.
Access data has direct or indirect addressing modes.
A set of 8-bit upper timer (Timer0) contains programmable frequency predivision lines.
A set of 10-bit downcount timers (Timer1) can optionally be loaded repeatedly or counted continuously.
Four 10-bit pulse width modulation outputs (PWM1~PWM4),PWM1/2/3/4 share Timer1.
A buzzer output (BZ1).
The 38/57KHz infrared carrier frequency can be selected, and the carrier polarity can also be selected according to the data.
Infrared carrier transmitter.
Built-in power-on reset circuit (POR).
Built-in low voltage reset (LVR).
Built-in watchdog timer (WDT), which can be switched on and off by the program firmware.
Dual clock mechanism, the system can switch between high speed oscillation or low speed oscillation at any time.
High speed oscillation: E_HXT(over 6MHz external high speed quartz oscillation)
E_XT(455K~6MHz external quartz oscillation)
I_HRC(1~20MHz internal high speed RC oscillation)
Low speed oscillation: E_LXT(32KHz external low speed quartz oscillation)
I_LRC(internal 32KHz low speed RC oscillation)
Four operating modes can be used to adjust current consumption according to system requirements: Normal mode, Slow mode, Standby mode, and sleep mode.
Six hardware interrupts:
Timer0 The overflow is interrupted.
Timer1 borrow interrupt.
The WDT is interrupted.
Description The change of PB input status is interrupted.
External interrupt input.
Low voltage detection interrupted.
Six wake interrupts for NY8A053E in Standby mode:
Timer0 The overflow is interrupted.
Timer1 borrow interrupt.
The WDT is interrupted.
Description The change of PB input status is interrupted.
External interrupt input.
Low voltage detection interrupted.
NY8A053E in Sleep mode (Halt mode) three wake interrupts:
The WDT is interrupted.
Description The change of PB input status is interrupted.
External interrupt input.
