TX2304
The TX2304 Series is a Synchronous step-up DC/DC Converter with PFM Control.With the TX2304 Series, a step-up switching DC/DC converter can be configured by using an external coil 、 capacitor. The built-in MOSFET is turned off by a protection circuit wh
TX2304 Description/概述：
The TX2304 Series is a Synchronous step-up DC/DC Converter with PFM Control.With the TX2304 Series, a step-up switching DC/DC converter can be configured by using an external coil 、 capacitor. The built-in MOSFET is turned off by a protection circuit when the voltage at the LX pin exceeds the limit to prevent it from being damaged.
TX2304 Features：
External parts: Coil, capacitor
Output voltage: Settable to between 2.1V to 5.0V in 0.1V steps
Maximum Oscillation frequency :300KHz
Accuracy of ±2%
High efficiency :95%
Package: SOT23, SOT23-3, SOT23-5,SOT89 and DFN1*1
TX2304 Applications/应用：
Digital cameras
Electronic notebooks and PDAS
Portable CD/MD players
Cameras, video equipment
Communications equipment
Power supply for microcomputers
TX2304 Block Diagram：
TX2304 Order Information：
TX2304-①②③④
Designator | Symbol | Description |
① ② | Integer | Output Voltage (2.1~5.0) e.g:3.0V=②：3；③：0 |
③ | N | Package: SOT23 |
M | Package: SOT23-3 | |
M5 | Package: SOT23-5 | |
P | Package: SOT89 | |
FC | Package: DFN1*1 | |
④ | G | Halogen Free |
TX2304 Pin Assignment：
TX2304 Application Circuits：
