NY9T004A-005b
Input: 1 for touch keys (PA0), 3 for mode selection (PA3, PE0, PE1),
Two timing switches (PA1, PA2).
PA0: Touch Key: short press or long press. There are 8 operation mode options, PA3, PE0,
PE1 for power-on bond selection.
NY9T004AS8-005b1 (Mode 1~4, no timing function)
NY9T004AS8-005b2 (Mode 5 to 8, none
Two timing switches (PA1, PA2).
PA0: Touch Key: short press or long press. There are 8 operation mode options, PA3, PE0,
PE1 for power-on bond selection.
NY9T004AS8-005b1 (Mode 1~4, no timing function)
NY9T004AS8-005b2 (Mode 5 to 8, none
NY9T004A-005b Function description
Action content:
Input: 1 for touch keys (PA0), 3 for mode selection (PA3, PE0, PE1),
Two timing switches (PA1, PA2).
Output: Two output outlets (PE2, PE3).
Trigger mode:
PA0: Touch Key: short press or long press. There are 8 operation mode options, PA3, PE0, PE1 for power-on bond selection.
Output signal:
PE2： PWM-IO， Drive。
PE3： PWM-IO， CSC 33%。
NY9T004A-005b DC parameters
Power supply voltage VDD: 2.0 ~ 6.0V
Static current Isb: 1.2uA@3.0V
(Touch Scan) 2.8uA@4.5V
Operating current (no load) Iop: 350uA @3.0V
500uA @4.5V
Output current (CMOS) Ioh: 10mA@3.0V
16mA @4.5V
Output Current (CSC 33%) Iol: 6.4mA @3.0V
6.7mA @4.5V
Oscillation Frequency： 400KHz
Low Voltage Reset： 1.8V
NY9T004A-005b application circuit and pin map
NY9T004A-005b Function Description
Timing selection: (Software Option, A toggle switch can be used while the program is running)
PA1, PA2 = x, x: no timing function.
PA1, PA2 = x, 1: timed for 30 minutes. (If there is a key operation in the timing, the timing function will reset the timing for 30 minutes)
PA1, PA2 = 1, x: timed for 60 minutes. (If a button is pressed during timing, the timing function will reset the timer for 60 minutes)
PA1, PA2 = 1, 1: timed for 90 minutes. (If there is a key operation in the timing, the timing function will reset the timing for 90 minutes)
NY9T004A-005b Mode options: (Bonding Option, which can only be switched during power-on)
NY9T004A-005b package IC pin
NY9T004A-005b Reference application circuit
NY9T004A-005b
DC5V Input (USB) +4... 2V rechargeable battery PE3 CSC-33% with PNP drive external LED light board (both ends of J7&J8)
Action content:
Input: 1 for touch keys (PA0), 3 for mode selection (PA3, PE0, PE1),
Two timing switches (PA1, PA2).
Output: Two output outlets (PE2, PE3).
Trigger mode:
PA0: Touch Key: short press or long press. There are 8 operation mode options, PA3, PE0, PE1 for power-on bond selection.
Output signal:
PE2： PWM-IO， Drive。
PE3： PWM-IO， CSC 33%。
NY9T004A-005b DC parameters
Power supply voltage VDD: 2.0 ~ 6.0V
Static current Isb: 1.2uA@3.0V
(Touch Scan) 2.8uA@4.5V
Operating current (no load) Iop: 350uA @3.0V
500uA @4.5V
Output current (CMOS) Ioh: 10mA@3.0V
16mA @4.5V
Output Current (CSC 33%) Iol: 6.4mA @3.0V
6.7mA @4.5V
Oscillation Frequency： 400KHz
Low Voltage Reset： 1.8V
NY9T004A-005b application circuit and pin map
NY9T004A-005b Function Description
Timing selection: (Software Option, A toggle switch can be used while the program is running)
PA1, PA2 = x, x: no timing function.
PA1, PA2 = x, 1: timed for 30 minutes. (If there is a key operation in the timing, the timing function will reset the timing for 30 minutes)
PA1, PA2 = 1, x: timed for 60 minutes. (If a button is pressed during timing, the timing function will reset the timer for 60 minutes)
PA1, PA2 = 1, 1: timed for 90 minutes. (If there is a key operation in the timing, the timing function will reset the timing for 90 minutes)
NY9T004A-005b Mode options: (Bonding Option, which can only be switched during power-on)
NY9T004A-005b package IC pin
NY9T004A-005b Reference application circuit
NY9T004A-005b
DC5V Input (USB) +4... 2V rechargeable battery PE3 CSC-33% with PNP drive external LED light board (both ends of J7&J8)
NY9T004A-005b
DC5V Input (USB) +4... 2V rechargeable battery
PE2 Drive with NPN drive external LED light board (both ends of J6&J7)
PE2 Drive with NPN drive external LED light board (both ends of J6&J7)
NY9T004A-005b
The DC12V input (Adaptor) is not connected to a rechargeable battery
PE2 Drive with NPN drive external LED light board (both ends of J6&J7)
The DC12V input (Adaptor) is not connected to a rechargeable battery
PE2 Drive with NPN drive external LED light board (both ends of J6&J7)
