ME6208
ME6208 series are low-dropout linear voltage regulators with a built-in voltage reference module, error correction module and phase compensation module. ME6208 series are based on the CMOS process and allow high voltage input with low quiescent current
ME6208 General Description:
ME6208 series are low-dropout linear voltage regulators with a built-in voltage reference module, error correction module and phase compensation module. ME6208 series are based on the CMOS process and allow high voltage input with low quiescent current. This series has the function of internal feedback resistor setting from 3.0V to 5.0V. The output accuracy is ± 2%.
ME6208 Features:
High output accuracy：±2%
Input voltage：up to 18V
Output voltage：3.0V ~ 5.0V
Ultra-low quiescent current (Typ.= 3µA)
Output Current：Iout=200mA（When Vin=7V and Vout=5V）
Importation good stability：Typ. 0.05%/V
Low temperature coefficient
Ceramic capacitor can be used
ME6208 Application:
Electronic weighbridge
SCM
Phones, cordless phones
Security Products
Water meters, power meters
ME6208 Package:
3-pin SOT23-3、SOT89-3、TO92
ME6208 Typical Application Circuit:
ME6208 Selection Guide:
product series | product description |
ME6208A21M3G | VOUT =2.1V； Package：M3,P,T |
ME6208A30M3G | VOUT =3.0V； Package：M3,P,T |
ME6208A33M3G | VOUT =3.3V； Package:：M3,P,T |
ME6208A36M3G | VOUT =3.6V； Package：M3,P,T |
ME6208A40M3G | VOUT =4.0V； Package:：M3,P,T |
ME6208A44M3G | VOUT =4.4V； Package：M3,P,T |
ME6208A50M3G | VOUT =5.0V； Package：M3,P,T |
ME6208 Pin Configuration/Pin Assignment:
ME6208 Block Diagram:
